b-DAC mkII

Pasted Graphic
• Models shipping from february 2013 onwards have a headphone output

Why would you need b-DAC ?
Improve playback from your existing CD player
Enhance the quality of your current network player
Enjoy high perfomance USB based playback

Features & specs V2.5 (current version)
• USB, SPDIF and optical inputs (5 in total), low jitter SPDIF output
• Balanced and single ended outputs, including volume control, drive your power amp directly
Low jitter Tentlabs clock (<1ps rms jitter) feeding the sample rate converter and dedicated reclocking stages
• 12 independent supply regulators, 3 shunt regulators
• SRC4382 upsampler, selectable sample rate
24 bits 192kHz PCM1792 DAC, al inputs reclocked
• -117dB distortion at 0dBfs (thd 0,0006%)
• Selectable filters and phase
• All functions remote controlled
Striking design, includes milled aluminium front panel and stainless steel cabinet

User manual
Download the version V2.3 (serial nrs up to #075) here
Download the version V2.5 (serial nrs #075 and higher) here

Customer feedback

Click here for more information about the next step in DAC conversion

• Retail price: € 999 (19% VAT included). Order now !
• Send an Email to stay informed
• Mono and stereo amplifiers b-Amp m and b-Amp s expected for delivery august 2012
• a CD transport and a discrete phono pre-amp will follow to complete the product range

24 bits USB
• Use this interface to fully explore all 24 bits from USB audio

• Go to our webshop
• Check out b-DAC dealers
